Brand:BENTLY NEVADA
Model: 3500/20
Status: New/Used
The Rack Interface Module (RIM) is the primary interface to the Bently Nevada™ 3500 rack. It supports a proprietary protocol used to configure the rack and retrieve machinery information. The RIM must be located in slot 1 of the rack (next to the power supplies). The RIM supports compatible Bently Nevada external communications processors such as TDXnet, TDIX, and DDIX. While the RIM provides certain functions common to the entire rack, the RIM is not part of the critical monitoring path and has no effect on the proper, normal operation of the overall monitoring system. One RIM is required per rack.
BENTLY NEVADA 3500/20
For Triple Modular Redundant (TMR) applications, the 3500 System requires a TMR version of the RIM. In addition to all the standard RIM functions, the TMR RIM also performs "monitor channel comparison." The 3500 TMR configuration implements monitor voting using the setup specified in the monitor options. Using this method, the TMR RIM continually compares the outputs from three (3) redundant monitors. If the TMR RIM detects that the information from one of those monitors is no longer within a configured percentof the information of the other two monitors, it will flag that the monitor is in error and place an event in the System Event List.
Other models: 3500/05 , 3500/15 , 3500/20 , 3500/22 , 3500/22M , 3500/25 , 3500/32 , 3500/32M , 3500/33 , 3500/34 , 3500/40 , 3500/40M , 3500/42 , 3500/42M , 3500/44M , 3500/45 , 3500/46M , 3500/50 , 3500/53 , 3500/60 , 3500/61 , 3500/62 , 3600/63 ， 3500/64M , 3500/70M , 3500/72M , 3500/77M , 3500/90 , 3500/92 , 3500/93 , 3500/93 System Display , 3500/94 , 3500/95……
Many products have not been launched yet. If you need more products, please contact us
Purchase consultation hotline: 18120742318
Email: [email protected]
3500/20机架接口模块
其他型号：3500/05 , 3500/15 , 3500/20 , 3500/22 , 3500/22M , 3500/25 , 3500/32 , 3500/32M , 3500/33 , 3500/34 , 3500/40 , 3500/40M , 3500/42 , 3500/42M , 3500/44M , 3500/45 , 3500/46M , 3500/50 , 3500/53 , 3500/60 , 3500/61 , 3500/62 , 3600/63 ， 3500/64M , 3500/70M , 3500/72M , 3500/77M , 3500/90 , 3500/92 , 3500/93 , 3500/93 System Display , 3500/94 , 3500/95……
QQ:3699232536
描述
机架接口模块（RIM）是Bently Nevada™3500机架的主要接口。它支持用于配置机架和检索机械信息的专有协议。后集成模块必须位于机架的插槽1中（电源旁边）。
RIM支持兼容的Bently Nevada外部通信处理器，如TDXnet、TDIX和DDIX。虽然后集成模块提供了整个机架的某些通用功能，但后集成模块不是关键监控路径的一部分，对整个监控系统的正常运行没有影响。每个机架需要一个RIM。
对于三模冗余（TMR）应用，3500系统需要TMR版本的RIM。除了所有标准RIM功能外，TMR RIM还执行“监测器信道比较”。3500 TMR配置使用监测器选项中指定的设置实现监测器投票。使用这种方法，TMR RIM会连续比较三（3）个冗余监视器的输出。如果TMR RIM检测到其中一个监视器的信息不再在其他两个监视器信息的配置百分比范围内，它将标记监视器出错并将事件放入系统事件列表中。
