Brand:FOXBORO
Model: FBI100
Part No：P0923LN
Status: New/Used
The FBI100 Fieldbus Isolator/Filter ensures that the 100 Series FBMs only receive the 268kbps communications intended for them, and not the 2 Mbps communications intended for the 200 Series FBMs. It also extends the total length of the 100 Series FBMs’ 268 Kbps Fieldbus.
FOXBORO FBI100
OVERVIEW
The FBI100 Fieldbus Isolator/Filter is designed to filter and isolate 2 Mbps communications from an I/A Series® Field Control Processor 270 to the Fieldbus Isolator (FBI) which requires 268 Kbps signals for 100 Series FBMs and similar Migration modules. The FCP270 can communicate with both 200 Series FBMs (over 2 Mbps signals) and 100 Series FBMs (over 268 Kbps signals) simultaneously and safely when the FBI100 is installed as specified.
The FBI100 outputs a 268 Kbps output signal identical to the typical 268 Kbps source from the FCP270. In addition, the FBI100 extends the 268 Kbps module Fieldbus up to 1830 m (6000 ft) over a twinaxial Fieldbus cable. The FBI100s are installed in a DIN rail mounted Modular Two-Slot vertical Baseplate for FBI100, which supports twinaxial cabling to the FBIs for the 100 Series FBMs.
FEATURES
Filters the FCP270’s 2 Mbps signals out, to ensure only the intended 268 Kbps signals reach the 100 Series FBMs, SPECTRUM, Fieldbus Cluster I/O cards and other 100 Series-based competitive migration devices.
Provides galvanically isolated drivers on the 100 Series module Fieldbus, supporting twinaxial cabling from the FBI100 to the 100 Series FBMs up to 1830 ms (6000 ft).
Two-Slot vertical baseplate for FBI100 accommodates two FBI100 modules - supports 268 Kbps HDLC module Fieldbus for 100 Series FBMs and other migration devices.
Harsh (Class G3 - ISA S71.04) contamination protection
Email: [email protected]
概述
FBI100现场总线隔离器/滤波器设计用于过滤和隔离从I/A Series®现场控制处理器270到现场总线隔离器（FBI）的2 Mbps通信，而100系列FBM和类似的迁移模块需要268 Kbps的信号。当按规定安装FBI100时，FCP270可以同时安全地与200系列FBM（超过2 Mbps的信号）和100系列FBMs（超过268 Kbps的信号）通信。
FBI100输出与FCP270的典型268Kbps源相同的268Kbps输出信号。此外，FBI100通过双轴现场总线电缆将268 Kbps模块现场总线扩展到1830米（6000英尺）。FBI100安装在用于FBI100的DIN导轨安装的模块化双槽垂直基板中，该基板支持100系列FBM的FBI的双轴布线。
特性
过滤掉FCP270的2 Mbps信号，以确保只有预期的268 Kbps信号到达100系列FBM、SPECTRUM、现场总线集群I/O卡和其他基于100系列的竞争性迁移设备。
在100系列模块现场总线上提供电隔离驱动器，支持从FBI100到100系列FBM的双轴布线，最长可达1830毫秒（6000英尺）。
FBI100的双插槽垂直基板可容纳两个FBI100模块，支持268 Kbps HDLC模块100系列FBM和其他迁移设备的现场总线。
恶劣（G3级-ISA S71.04）污染防护
