FOXBORO FBM239

The FBM239 contains 16 discrete input and 16 discrete output channels that are compatible with voltages and currents commonly found in industrial plants. An external power supply is used to energize the field circuits.

The FBM239 Discrete 16DI/16DO Module provides 16 digital inputs with sixteen digital output channels. Associated Termination Assemblies (TAs) and Termination Assembly Adapters (TAAs) provide for discrete nominal inputs of 30 V dc, 60 V dc, 120 V ac/125 V dc or 240 V ac and nominal outputs of 60 V dc, 120 V ac/125 V dc or 240 V ac. The module performs signal conversion required to interface the electrical input signals from the field sensors to the Module Fieldbus.

Depending on the type of I/O signal required, the TAs or TAAs support current limiting devices, high voltage attenuation circuits, optical isolation and external power source connections. When connected to the appropriate Termination Assembly Adapters (TAAs) or TAs, the FBM239 module provides functionality formerly provided by the 100 Series FBM I/O subsystem. TAAs and TAs are available which support the functionality of the main FBM09, FBM10, FBM11, FBM26 and FBM41 (8 input/ 8 output main FBMs). These main FBMs may be used with expansion FBM14, FBM15, FBM16, FBM27 or FBM42 (8 input/8/output expansion FBMs).

Email: [email protected]

FBM239包含16个离散输入和16个离散输出通道，与工业厂房中常见的电压和电流兼容。外部电源用于为现场电路供电。
FBM239离散16DI/16DO模块提供16个数字输入和16个数字输出通道。相关端接组件（TA）和端接组件适配器（TAA）提供30 V dc、60 V dc、120 V ac/125 V dc或240 V ac的离散标称输入和60 V dc，120 V ac/125 V dc或240V ac的标称输出。该模块执行将现场传感器的电气输入信号连接到模块现场总线所需的信号转换。
根据所需I/O信号的类型，TA或TAA支持限流设备、高压衰减电路、光隔离和外部电源连接。当连接到适当的终端组件适配器（TAA）或TA时，FBM239模块提供以前由100系列FBM I/O子系统提供的功能。TAA和TA支持主FBM09、FBM10、FBM11、FBM26和FBM41（8输入/8输出主FBM）的功能。这些主要的FBM可以与扩展FBM14、FBM15、FBM16、FBM27或FBM42（8输入/8/输出扩展FBM）一起使用。
