ABB 83SR07 (GJR2392700R1210)

Brand: ABB

Model: 83SR07

Part No: GJR2392700R1210

Describe: Control Module

Status: New/Used

The ABB 83SR07 GJR2392700R1210 analog control module is a high-performance analog signal interface unit designed specifically for precise signal processing in industrial automation and control systems. It is part of ABB's highly acclaimed control and I/O module series, primarily used for ABB's Symphony Harmony or INFI 90 control systems.

[email protected]

ABB 83SR07 (GJR2392700R1210)

The module is used for stored-program analog control of one or two process variables. The module is provided with two continuous outputs for output of the correcting variables. The following types of actuators can be controlled:

- electrohydraulic actuators

- electropneumatic actuators

- electric-motor-powered drives

The drives are positioned either locally at the transducer or in case of electric-motor-powered actuators, in a continuously operating power electronics system. It is also possible to supplement the single variable analog controls by a higherlevel master control system.

The module is intended for use in connection with the process operator station.

The module incorporates the function blocks for implementing continuous single variable controllers. Additional function blocks are available for signal conditioning.

In the analog control mode, the module is used with fixed cycle times. This is 100 ms for one actuator and 200 ms for two actuators.

The cycle time is specified by means of function block KON, which is the first block to appear in the structure.

The module incorporates two hardware process interfaces for the power controller units and the process.

Many products have not been launched yet. If you need more products, please contact us

Purchase consultation hotline: 18120742318

QQ：3699232536

Email: [email protected]

ABB 83SR07 GJR2392700R1210 模拟控制模块是一款高性能模拟信号接口单元，专为工业自动化和控制系统中的精确信号处理而设计。它是 ABB 广受好评的控制和 I/O 模块系列的一部分，主要用于 ABB 的 Symphony Harmony 或 INFI 90 控制系统。

该模块用于一个或两个过程变量的存储程序模拟控制。该模块配备了两个连续输出，用于输出校正变量。可以控制以下类型的执行器：
-电动液压执行器
-电动气动执行器
-电动机驱动装置
驱动器位于传感器的本地，或者在电机驱动的执行器的情况下，位于连续运行的电力电子系统中。还可以通过更高级别的主控制系统来补充单变量模拟控制。
该模块旨在与过程操作员站结合使用。
该模块包含用于实现连续单变量控制器的功能块。其他功能块可用于信号调节。
在模拟控制模式下，该模块以固定的循环时间使用。对于一个执行器，这是100毫秒，对于两个执行器是200毫秒。
循环时间由功能块KON指定，KON是结构中出现的第一个块。
该模块包含两个用于电源控制器单元和过程的硬件过程接口。
