ABB AC800PEC PP D113 (3BHE023784)

Brand: ABB

Model: AC800PEC PP D113

Part No: 3BHE023784

Describe: High performance controller

Status: New/Used

The high-performance control system for high power rectifier applications.High-performance applications with extremely fast control algorithms – cycle times that range from 100 μs (microseconds) for fast control loops to seconds for long-term operational transients – require specialized control devices.

[email protected]

ABB AC800PEC PP D113 (3BHE023784)

That is why we have designed the AC 800PEC, extending the capabilities of ABB’s well-known automation technology to handle the high-speed algorithms of processes such as power electronic applications.

AC 800PEC controller to achieve it. Taking the technology a step further it is a dualcore processor unit that combines these highspeed controls with the low-speed process control tasks usually carried out by separate PLC (programmable logic controller) units. Embedded into a robust and flexible system structure

The AC 800PEC has a unique combination of features for demanding applications:

• Short cycle times, down to 100 μs

• High processing power

• Fast communication and I/O via optical links

• Programming tools:

- System engineering with IEC61131-3 languages using ABB’s Control Builder, both Compact and Professional versions available

- Product and control development using MATLAB®/Simulink® for model-based design, easily bridging the gap from simulation to

implementation

• Full integration into ABB Ability™ System 800xA

• Innovative and flexible use of FPGAs to include protocols and application functionality in the devices without creating additional processor

load

• Optical communication

• Industrial grade hardware with no moving parts

• Long life cycle, easy upgrading

• Robust reliance file system, insusceptible post power loss

Many products have not been launched yet. If you need more products, please contact us

Purchase consultation hotline: 18120742318

QQ：3699232536

Email: [email protected]

用于大功率整流器应用的高性能控制系统。具有极快控制算法的高性能应用——快速控制回路的循环时间从100μs（微秒）到长期运行瞬态的几秒钟不等——需要专门的控制设备。
这就是为什么我们设计了AC 800PEC，扩展了ABB著名的自动化技术的能力，以处理电力电子应用等过程的高速算法。
AC 800PEC控制器来实现它。更进一步，它是一个双核处理器单元，将这些高速控制与通常由单独的PLC（可编程逻辑控制器）单元执行的低速过程控制任务相结合。嵌入到稳健灵活的系统结构中
AC 800PEC具有独特的功能组合，适用于要求苛刻的应用：
•循环时间短，低至100μs
•高处理能力
•通过光链路实现快速通信和I/O
•编程工具：
-使用ABB的Control Builder，使用IEC61131-3语言进行系统工程，提供紧凑版和专业版
-使用MATLAB®/Simulink®进行基于模型的设计的产品和控制开发，轻松弥合从仿真到
实施
•完全集成到ABB Ability™系统800xA中
•创新灵活地使用FPGA，在设备中包含协议和应用程序功能，而无需创建额外的处理器
负载
•光通信
•工业级硬件，无活动部件
•生命周期长，易于升级
•强大的依赖文件系统，不易受到断电后的影响

许多产品尚未推出。如果您需要更多产品，请联系我们
购买咨询热线:18120742318

QQ:3699232536

邮箱:[email protected]
