SST-PB3-CLX

Maximise network flexibility with SST™ CommunicationModules for rapid connection of Rockwell ControlLogixsystems to PROFIBUS networks

Features and Benefits：

Connects Rockwell ControlLogixto a PROFIBUS network Fully integrated into the Rockwell

• Automation environment- Remote configuration and monitoring via Rockwell RSLinx™

• Add-On-Profile for Rockwell RSLogix5000

Specifications

DESCRIPTION

High-speed deterministic communication

Easy diagnostics:

Built-in LEDs and 4 characters display Manage DP Master and Slave modes simultaneously Allows changes to PROFIBUS configuration with PLC in RUN mode Dynamically add/remove PROFIBUS slaves from the scan list CommDTM driver for FDT Frame engineering software (PACTware™, FieldCare™, FieldMate™, etc) Auto-Boot(Configuration stored in Flash)

Engineering Tools:

• Configuration console

• Test and diagnostic tools

COMPATIBLE PROTOCOLS

Master DP-V0 Class-1 and Class-2 Master DP-V1 Class-1 and Class-2 Slave DP-V0 Direct IO Mapping, no Ladder Logic to write for configuration and data transfer between module and CLX processor

Conformal coated version:

• Protects electronic boards from moisture and contaminants

CLXT modules feature wider temperature ranges and conformal coated, harsh-duty components for use with Rockwell XT PLCs

INCLUDED HARDWARE/SOFTWARE

Add-On-Profile for increased functionality and reduced commissioning time Support multiple modules in a chassis; support Local and Remote chassis One PROFIBUS port, DB9 female,Galvanic insulation 1000V Speed: 9.6 Kbps up to 12 Mbps LEDs for system, communication,and network status Up to 1984 Input Bytes and 1968 Output Bytes One Serial port for configuration and diagnostic Firmware upgradeable

CLXT MODULE: Same specifications as SST-PB3-CLX-RLL plus: Conformal coating eXTreme components Ambient Operating Temperature-25 to 70°C

Typical System Architecture

Ordering Information
