GE IC697BEM731U

IC697BEM731 is a Bus Controller Module (BCM) manufactured by GE Fanuc for the 90-70 Series. IC697BEM731 is designed specifically for the Genius I/O handheld monitor IC660/IC661. The IC697BEM731 module is available as a single channel controller; thus it only occupies a single handheld monitor (IC66*) PLC slot. This BCM scans IC66* input/output blocks asynchronously; consequently, I/O data is transferred to the CPU once per scan over the backplate of the IC697 PLC rack. The IC697BEM731 BCM is also charged with the task of supporting directed communication originating from a PLC CPU communication service request. In addition, it may be configured to perform global communications. The IC697BEM731 can only be configured by the MS DOS or Windows programming software configuration function.

Additional features of the IC697BEM731 include 30 drops per channel, IC66* or IC661 I/O diagnostics, support of redundant blocks, cables, and CPUs, LAN communications, CPU soft configuration, and an alarm processor function. Before installing, refer to the applicable PLC installation manual. The power should be OFF before starting. Install the rack as instructed, and turn power ON. If done correctly, the module will power up with a corresponding blinking LED. The middle LED will emit ON when configuration is received from the CPU and the bus operation verified. The LED on the bottom is always OFF.

Product Features:

• Single-channel Genius Bus Controller for distributed automation architectures.

• Supports up to 30 devices per channel with asynchronous scanning and data transfer.

• Flexible configuration via HHM port and Windows/MS-DOS tools.

• Proven reliability in harsh industrial environments with redundancy support.

Many products have not been launched yet. If you need more products, please contact us

Purchase consultation hotline: 18120742318

QQ：3699232536

Email: [email protected]

IC697BEM731是GE Fanuc为90-70系列制造的总线控制器模块（BCM）。IC697BEM731是专为Genius I/O手持显示器IC660/IC661设计的。IC697BEM731模块可作为单通道控制器使用；因此，它只占用一个手持监视器（IC66*）PLC插槽。该BCM异步扫描IC66*输入/输出块；因此，每次扫描时，I/O数据都会通过IC697 PLC机架的背板传输到CPU一次。IC697BEM731 BCM还负责支持源自PLC CPU通信服务请求的定向通信。此外，它可以被配置为执行全局通信。IC697BEM731只能通过MS-DOS或Windows编程软件配置功能进行配置。
IC697BEM731的其他功能包括每通道30次分接、IC66*或IC661 I/O诊断、支持冗余块、电缆和CPU、LAN通信、CPU软配置和报警处理器功能。安装前，请参阅适用的PLC安装手册。启动前应关闭电源。按照指示安装机架，然后打开电源。如果操作正确，模块将通电，并显示相应的闪烁LED。当从CPU收到配置并验证总线操作时，中间的LED将亮起。底部的LED始终处于关闭状态。

产品特点：

• 用于分布式自动化架构的单通道Genius总线控制器。
• 通过异步扫描和数据传输，每个通道最多支持30个设备。
• 通过HHM端口和Windows/MMS-DOS工具进行灵活配置。

• 在恶劣的工业环境中经过验证的可靠性，具有冗余支持。
