Brand:GE

Model: IC697CMM742

Part No: IC697CMM742

Describe: Ethernet interface module

Status: New/Used

The IC697CMM742 Ethernet Interface (Type 2) provides high performance TCP/IP communications for the IC697 PLC.

[email protected]

GE IC697CMM742

The IC697CMM742 Ethernet Interface (Type 2) provides high performance TCP/IP communications for the IC697 PLC.

The Ethernet Interface (Type 2) plugs into a single slot in an IC697 PLC rack and is configured with the IC641 PLC programming software. Up to four Ethernet Interface (Type 2) modules can be installed in an IC697 PLC CPU rack. The Ethernet Interface (Type 2) contains three network ports: 10BaseT (RJ-45 connector), 10Base2 (BNC connector), and AUI (15-pin D-connector). The Ethernet Interface automatically selects the network port in use. One network port may be used at a time.

Features

Connects IC697 PLC to an IEEE 802.3 CSMA/CD 10Mbps Ethernet LAN via one of three network ports: 10BaseT, 10Base2, or AUI

10BaseT and 10Base2 network ports provide direct connection to 10BaseT or 10Base2 network without an external transceiver

Standard 15-pin AUI network port allows choice of 10Base5, 10Base2, 10BaseT, 10BaseF, or 10Broad36 medium with user-supplied 802.3-compatible transceiver

Firmware is pre-loaded for easy installation and is maintained indefinitely; firmware is easily upgraded in-system from PC attached to RS-485 serial port

The Ethernet Interface provides:

1.Data exchange using configuration-based and logic-based Ethernet Global Data

2.TCP/IP communication services using SRTP

3.Full PLC programming and configuration services

4.Comprehensive station management and diagnostic tools

Many products have not been launched yet. If you need more products, please contact us

Purchase consultation hotline: 18120742318

QQ：3699232536

Email: [email protected]

IC697CMM742以太网接口（2型）为IC697 PLC提供高性能TCP/IP通信。
以太网接口（类型2）插入IC697 PLC机架中的单个插槽，并配置有IC641 PLC编程软件。IC697 PLC CPU机架中最多可以安装四个以太网接口（2型）模块。以太网接口（类型2）包含三个网络端口：10BaseT（RJ-45连接器）、10Base2（BNC连接器）和AUI（15针D连接器）。以太网接口会自动选择正在使用的网络端口。一次只能使用一个网络端口。

特性
通过三个网络端口之一将IC697 PLC连接到IEEE 802.3 CSMA/CD 10Mbps以太网LAN：10BaseT、10Base2或AUI
10BaseT和10Base2网络端口提供直接连接到10BaseT或10Base2的网络，无需外部收发器
标准15针AUI网络端口允许选择10Base5、10Base2、10BaseT、10BaseF或10Broad36介质，并配备用户提供的兼容802.3的收发器

固件已预加载，便于安装，并可无限期维护；固件可以很容易地从连接到RS-485串行端口的PC升级到系统中

以太网接口提供：
1.使用基于配置和基于逻辑的以太网全局数据进行数据交换
2.使用SRTP的TCP/IP通信服务
3.完整的PLC编程和配置服务
4.综合站点管理和诊断工具
