Brand:GE
Model: IC698PSA100
Part No: IC698PSA100
Describe: power module
Status: New/Used
IC698PSA100 is a versatile Power Supply Module manufactured by GE Fanuc for the RX7i series. This PACSystems module delivers +5 VDC, +12 VDC, and -12 VDC power as well as logic level sequencing signals to modules on the backplane. The module plugs straight into slot 0 in the main rack. The IC698PSA100 module’s power supply output can lose up to one AC input line cycle without actually losing output power. Overcurrent, overtemperature, and overvoltage fault conditions are also protected. The module allows 100 watts total output power at ambient temperatures of 0 to 60ºC with no forced air cooling.
GE IC698PSA100
The IC698PSA100 power supply module is an Rx7i PACsystem modern power supply module manufactured by GE. It comes with a nominal voltage rating of 120/240 Volts AC or 125 Volts DC. The input voltage range of the power supply is in between 85 and 264 Volts AC or 100 and 150 Volts DC. The power supply module resides in the leftmost slot or slot 0 of the Rx7i system backplane. The power rating of the module is 125 Watts. It has an output voltage of 5 Volts DC, 12 Volts DC, and -12 Volts DC. The IC698PSA100 power supply module sends logic level signals to the modules by using the backplane of the system. The power supply module is enhanced in terms of safety and protection. Its protected from over-current, over-temperature, and over-voltage situations. The IC698PSA100 power supply module is equipped with a switch that is located on the front side of the power supply. It helps to enable or disable the output channel and it does not interfere with the AC line input. LED indicators are present in the power supply module and they alert the operators about different things. The LEDs are the FIELD OK, OUTPUT OK, and OVER TEMP LEDs. The IC698PSA100 power supply module has a power factor of 0.99 min. The isolation in the module is 1500 Volts DC. The power supply also offers a ride-through of 15 milliseconds without affecting the DC outputs and a hold up time of 5 milliseconds when the DC output drops out. The IC698PSA100 power supply module needs an operating temperature range between 0 and 60 degrees Celsius. The module has been certified to operate in a Class 1 Division 2 environment.
Rack Location: Slot 0 (Leftmost slot)
Email: [email protected]
IC698PSA100电源模块是GE公司生产的Rx7i PACsystem的现代电源模块。其额定电压为120/240伏交流电或125伏直流电。电源的输入电压范围为85至264伏交流电或100至150伏直流电。该电源模块位于Rx7i系统背板的最左侧插槽或插槽0中。模块的额定功率为125瓦。其输出电压包括5伏直流电、12伏直流电和-12伏直流电。IC698PSA100电源模块通过系统背板向其他模块发送逻辑电平信号。该电源模块在安全和保护方面得到了增强，能够防止过电流、过温和过电压情况的发生。IC698PSA100电源模块配备了一个位于电源前侧的开关，用于启用或禁用输出通道，且不会干扰交流线路输入。电源模块中设有LED指示灯，用于向操作人员发出不同情况的警报。这些LED指示灯包括现场正常（FIELD OK）、输出正常（OUTPUT OK）和过热（OVER TEMP）指示灯。IC698PSA100电源模块的功率因数至少为0.99。模块中的隔离电压为1500伏直流电。该电源还具有15毫秒的穿越能力，不会影响直流输出，并且在直流输出下降时具有5毫秒的保持时间。IC698PSA100电源模块的工作温度范围为0至60摄氏度。该模块已通过认证，可在1类2区环境中运行。
标称额定电压：120/240 VAC或125 VDC
输入电压范围：85至264 VAC或100至150 VDC
输入功率：125瓦
输出电压：+5 VDC、+12 VDC或-12VDC
模块类型：电源
机架位置：插槽0（最左侧插槽）
