Consen（康吉森） CM01
Brand: Consen（康吉森）
Model: CM01
Status: New/Used
CM01 is responsible for the communication between Control Station and PC software, communication between Control Stations, and communication between Control Station and third party system. CM01 is also used to implement synchronization function. CM01 communicates with the third party system via Modbus protocol. One option is via Modbus TCP protocol, which is running in Ethernet (System Net), while the other option is via Modbus RTU/ASCII protocol, which is RS485/422 communication.
Consen（康吉森） CM01
Consen CM01 Communication Module
CM01 is responsible for the communication between Control Station and PC software, communication between Control Stations, and communication between Control Station and third party system. CM01 is also used to implement synchronization function.
CM01 communicates with the third party system via Modbus protocol. One option is via Modbus TCP protocol, which is running in Ethernet (System Net), while the other option is via Modbus RTU/ASCII protocol, which is RS485/422 communication.
Main Parameters:
Input voltage:24VDC
Hot swap:Suppart
Redundant Power Supply:Yes
CPU:Industrial high reliability dual core CPU
FLASH Capacity:64MBytes , 32-bit CRC
Port RJ45:2 x Ethernet Port NTP/SNTP Timing Synchronization10/100/1000BASE-T (X)self-adaption,automatic MDl/MDIX Modbus-Tcp protocol Master and slave configurable
Port Modbus:4 x Serical Port Modbus-RTU /ASCll protocol Master or Slave Mode 2xRS485，2xRS485/RS422 Port4 GPS Timing Synchronization
Size(H*D*W):352mm*355mm*19mm
Weight:1.55kg
Purchase consultation hotline: 18120742318
QQ：3699232536
Email: [email protected]
Consen CM01通信模块
CM01负责控制站与PC软件之间的通信、控制站之间的通信以及控制站与第三方系统之间的通信。CM01还用于实现同步功能。CM01通过Modbus协议与第三方系统通信。一种选择是通过Modbus TCP协议，该协议在以太网（System Net）中运行，而另一种选择则是通过Modbus RTU/ASCII协议，即RS485/422通信。
主要参数：
输入电压：24VDC
热插拔：支持
冗余电源：是
CPU：工业级高可靠性双核CPU
闪存容量：64MB，32位CRC
RJ45接口:2 个以太网端口NTP/SNTP定时同步10/100/1000BASE-T（X）自适应，自动MDl/MDIXModbus Tcp协议主从可配置
Modbus接口：4个串行端口Modbus RTU/ASCll协议主或从模式2xRS485/2RS485/RS422端口4 GPS定时同步
尺寸（高*深*宽）：352毫米*355毫米*19毫米
重量：1.55kg
