Brand:Schneider Electric
Model: ATS48D88Q
Describe: Schneider soft starter
Status: New/Used
This Altistart 48 soft start/soft stop unit is a controller with 6 thyristors used for torque-controlled soft starting and stopping of three-phase asynchronous motors. It offers soft starting and deceleration functions along with machine and motor protection functions, as well as functions for communicating with control systems. It works at a rated supply voltage from 230V to 415V AC and up to 88A rating. Altistart 48 torque control enables starting without mechanical stress and smooth control of hydraulic transitions, with a single acceleration ramp making adjustments is quick and easy, whatever the load.
Schneider Electric ATS48D88Q
ATS48D88Q soft starter for asynchronous motor, Altistart 48, 81A, 230 to 415V, 18.5 to 75kW
This Altistart 48 soft start/soft stop unit is a controller with 6 thyristors used for torque-controlled soft starting and stopping of three-phase asynchronous motors. It offers soft starting and deceleration functions along with machine and motor protection functions, as well as functions for communicating with control systems. It works at a rated supply voltage from 230V to 415V AC and up to 88A rating. Altistart 48 torque control enables starting without mechanical stress and smooth control of hydraulic transitions, with a single acceleration ramp making adjustments is quick and easy, whatever the load. If connected in the motor supply line it is suitable for motors with power rating up to 45kW (at 400V) for standards applications and 37kW (at 400V) for severe applications. If connected to the motor delta terminals it is suitable for motors with power rating up to 75kW (at 400V) for standards applications and 55kW (at 400V) for severe applications. It weighs 8.3kg and its dimensions are, 190mm wide, 290mm high, 235mm deep. It is designed for use in the most common applications for centrifugal machines, pumps, fans, compressors and conveyors, which are primarily to be found in the construction, food and beverage and chemical industries. It complies with IEC/EN 60947-4-2 standard and is certified CE, UL, CSA, DNV, C-Tick, GOST, CCC, NOM, SEPRO, and TCF. The Altistart 48 is connected directly to the Modbus bus via its RJ45 connector port, It can also be connected to Ethernet, Fipio, Profibus DP and DeviceNet networks via a module (bridge or gateway) to order separately. It is designed to be mounted in vertical position (+/- 10 °) on a panel, thanks to 4 fixing holes. Altistart 48 delivers high performance with its Torque Control System (TCS) for controlled starting and deceleration, an easy integration in enclosures and control systems. This range provides also continual improvement of your machine operation by reducing mechanical or hydraulic stress and limiting energy loss and temperature rise, plus more.
ATS48D88Q is replaced by:ATS480D88Y （Soft starter, Altistart 480, 88A, 208 to 690V AC, control supply 110 to 230V AC）
Many products have not been launched yet. If you need more products, please contact us
Email: [email protected]
ATS48D88Q异步电动机软起动器，Altistart 48，81A，230至415V，18.5至75kW
Altistart 48软启动/软停止装置是一个带有6个晶闸管的控制器，用于三相异步电动机的扭矩控制软启动和停止。它提供软启动和减速功能，以及机器和电机保护功能，以及与控制系统通信的功能。它在230V至415V AC的额定电源电压下工作，额定电流高达88A。Altistart 48扭矩控制能够在没有机械应力的情况下启动，并通过单个加速斜坡平稳控制液压转换，无论负载如何，调整都是快速而简单的。如果连接在电机供电线路中，则适用于额定功率高达45kW（400V时）的标准应用电机和额定功率为37kW（400V时）的恶劣应用电机。如果连接到电机三角端子，则适用于额定功率高达75kW（400V时）的标准应用电机和55kW（400V时）的恶劣应用电机。它重8.3公斤，尺寸为190毫米宽，290毫米高，235毫米深。它专为离心机、泵、风扇、压缩机和输送机的最常见应用而设计，这些应用主要存在于建筑、食品和饮料以及化学工业中。它符合IEC/EN 60947-4-2标准，并通过了CE、UL、CSA、DNV、C-Tick、GOST、CCC、NOM、SEPRO和TCF认证。Altistart 48通过其RJ45连接器端口直接连接到Modbus总线，也可以通过模块（网桥或网关）连接到以太网、Fibio、Profibus DP和DeviceNet网络，以便单独订购。由于有4个固定孔，它被设计为垂直安装在面板上（+/-10°）。Altistart 48通过其扭矩控制系统（TCS）提供高性能，用于控制启动和减速，可轻松集成到外壳和控制系统中。该系列还通过减少机械或液压应力、限制能量损失和温升等，不断改进您的机器操作。
ATS48D88Q替换为：ATS480D88Y（软启动器，Altistart 480，88A，208至690V交流电，控制电源110至230V交流电）
