Brand:Schneider Electric
Model: 170ADM39010
Describe: Distributed analog output
Status: New/Used
The 170ADM39010 module has a wire breakage detection function, and the 56 kOhm resistor on the module's wiring diagram is used to achieve the module's wire breakage detection function. Its connection must be directly connected to the 2-wire device. If a 56 kiloohm resistor is not connected as shown in the diagram, the module will still report a circuit disconnection error even when the device is in a normal logic zero state.
Schneider Electric 170ADM39010
discrete I/O module Modicon Momentum - 16I / 12O solid state 170ADM39010
170ADM39010 is a distributed analog output with 4 outputs and 4.20 Ma, manufactured by Schneider Electric.
The 170ADM39010 module has a wire breakage detection function, and the 56 kOhm resistor on the module's wiring diagram is used to achieve the module's wire breakage detection function. Its connection must be directly connected to the 2-wire device. If a 56 kiloohm resistor is not connected as shown in the diagram, the module will still report a circuit disconnection error even when the device is in a normal logic zero state.
Many products have not been launched yet. If you need more products, please contact us
